用于开裂和非开裂混凝土中承受重荷载的通孔锚栓. ETA 1级认证,亚特兰蒂斯C4-L 螺杆,不锈钢夹片
评估与认证
ETA CU 12-0397
Fire restistant
SEISMIC C1
SEISMIC C1&C2
CE 2012
VDS
尺寸
最大固定厚度 [mm]
基材最小厚度 [mm]
轴标识(长度)
最小销售单位
彩盒件数
外箱件数
Technical Info.
M6 x 60 Ø6
10
100
B
0
200
1.200
tfix - 最大夹具厚度10
SW-安装关键10
df - Ø 元件固定7
Tins - 扭矩 (Nm)7
hef - 有效深度40
hnom - 最小锚固深度46
h1 - 钻孔最小深度50
d0 - Ø 钻头6
hmin - Min. substrate thickness100
L- 长度60
M6 x 70 Ø6
20
100
C
0
200
1.200
tfix - 最大夹具厚度20
SW-安装关键10
df - Ø 元件固定7
Tins - 扭矩 (Nm)7
hef - 有效深度40
hnom - 最小锚固深度46
h1 - 钻孔最小深度50
d0 - Ø 钻头6
hmin - Min. substrate thickness100
L- 长度70
M6 x 100 Ø6
50
100
E
0
200
800
tfix - 最大夹具厚度50
SW-安装关键10
df - Ø 元件固定7
Tins - 扭矩 (Nm)7
hef - 有效深度40
hnom - 最小锚固深度46
h1 - 钻孔最小深度50
d0 - Ø 钻头6
hmin - Min. substrate thickness100
L- 长度100
M8 x 50 Ø8
2
100
A
0
100
800
tfix - 最大夹具厚度2
SW-安装关键13
df - Ø 元件固定9
Tins - 扭矩 (Nm)15
hef - 有效深度30
hnom - 最小锚固深度37
h1 - 钻孔最小深度40
d0 - Ø 钻头8
hmin - Min. substrate thickness100
L- 长度50
M8 x 60 Ø8
12
100
B
0
100
800
tfix - 最大夹具厚度12
SW-安装关键13
df - Ø 元件固定9
Tins - 扭矩 (Nm)15
hef - 有效深度30
hnom - 最小锚固深度37
h1 - 钻孔最小深度40
d0 - Ø 钻头8
hmin - Min. substrate thickness100
L- 长度60
M8 x 75 Ø8
9
100
C
0
100
600
tfix - 最大夹具厚度9
SW-安装关键13
df - Ø 元件固定9
Tins - 扭矩 (Nm)15
hef - 有效深度48
hnom - 最小锚固深度55
h1 - 钻孔最小深度60
d0 - Ø 钻头8
hmin - Min. substrate thickness100
L- 长度75
M8 x 95 Ø8
29
100
E
0
100
600
tfix - 最大夹具厚度29
SW-安装关键13
df - Ø 元件固定9
Tins - 扭矩 (Nm)15
hef - 有效深度48
hnom - 最小锚固深度55
h1 - 钻孔最小深度60
d0 - Ø 钻头8
hmin - Min. substrate thickness100
L- 长度95
M8 x 115 Ø8
49
100
G
0
100
400
tfix - 最大夹具厚度49
SW-安装关键13
df - Ø 元件固定9
Tins - 扭矩 (Nm)15
hef - 有效深度48
hnom - 最小锚固深度55
h1 - 钻孔最小深度60
d0 - Ø 钻头8
hmin - Min. substrate thickness100
L- 长度115
M10 x 70 Ø10
5
100
C
0
100
400
tfix - 最大夹具厚度5
SW-安装关键17
df - Ø 元件固定12
Tins - 扭矩 (Nm)40
hef - 有效深度45
hnom - 最小锚固深度53
h1 - 钻孔最小深度60
d0 - Ø 钻头10
hmin - Min. substrate thickness100
L- 长度70
M10 x 90 Ø10
10
120
E
0
100
400
tfix - 最大夹具厚度10
SW-安装关键17
df - Ø 元件固定12
Tins - 扭矩 (Nm)40
hef - 有效深度60
hnom - 最小锚固深度68
h1 - 钻孔最小深度75
d0 - Ø 钻头10
hmin - Min. substrate thickness120
L- 长度90
M10 x 105 Ø10
25
120
F
0
50
300
tfix - 最大夹具厚度25
SW-安装关键17
df - Ø 元件固定12
Tins - 扭矩 (Nm)40
hef - 有效深度60
hnom - 最小锚固深度68
h1 - 钻孔最小深度75
d0 - Ø 钻头10
hmin - Min. substrate thickness120
L- 长度105
M10 x 115 Ø10
35
120
G
0
50
200
tfix - 最大夹具厚度35
SW-安装关键17
df - Ø 元件固定12
Tins - 扭矩 (Nm)40
hef - 有效深度60
hnom - 最小锚固深度68
h1 - 钻孔最小深度75
d0 - Ø 钻头10
hmin - Min. substrate thickness120
L- 长度115
M10 x 135 Ø10
55
120
H
0
50
200
tfix - 最大夹具厚度55
SW-安装关键17
df - Ø 元件固定12
Tins - 扭矩 (Nm)40
hef - 有效深度60
hnom - 最小锚固深度68
h1 - 钻孔最小深度75
d0 - Ø 钻头10
hmin - Min. substrate thickness120
L- 长度135
M10 x 165 Ø10
85
120
K
0
50
200
tfix - 最大夹具厚度85
SW-安装关键17
df - Ø 元件固定12
Tins - 扭矩 (Nm)40
hef - 有效深度60
hnom - 最小锚固深度68
h1 - 钻孔最小深度75
d0 - Ø 钻头10
hmin - Min. substrate thickness120
L- 长度165
M10 x 185 Ø10
105
120
L
0
50
150
tfix - 最大夹具厚度105
SW-安装关键17
df - Ø 元件固定12
Tins - 扭矩 (Nm)40
hef - 有效深度60
hnom - 最小锚固深度68
h1 - 钻孔最小深度75
d0 - Ø 钻头10
hmin - Min. substrate thickness120
L- 长度185
M12 x 80 Ø12
4
100
D
0
50
300
tfix - 最大夹具厚度4
SW-安装关键19
df - Ø 元件固定14
Tins - 扭矩 (Nm)60
hef - 有效深度50
hnom - 最小锚固深度60
h1 - 钻孔最小深度65
d0 - Ø 钻头12
hmin - Min. substrate thickness100
L- 长度80
M12 x 110 Ø12
14
140
F
0
50
200
tfix - 最大夹具厚度14
SW-安装关键19
df - Ø 元件固定14
Tins - 扭矩 (Nm)60
hef - 有效深度70
hnom - 最小锚固深度80
h1 - 钻孔最小深度85
d0 - Ø 钻头12
hmin - Min. substrate thickness140
L- 长度110
M12 x 130 Ø12
34
140
H
0
50
200
tfix - 最大夹具厚度34
SW-安装关键19
df - Ø 元件固定14
Tins - 扭矩 (Nm)60
hef - 有效深度70
hnom - 最小锚固深度80
h1 - 钻孔最小深度85
d0 - Ø 钻头12
hmin - Min. substrate thickness140
L- 长度130
M12 x 150 Ø12
54
140
I
0
50
100
tfix - 最大夹具厚度54
SW-安装关键19
df - Ø 元件固定14
Tins - 扭矩 (Nm)60
hef - 有效深度70
hnom - 最小锚固深度80
h1 - 钻孔最小深度85
d0 - Ø 钻头12
hmin - Min. substrate thickness140
L- 长度150
M12 x 180 Ø12
84
140
L
0
50
150
tfix - 最大夹具厚度84
SW-安装关键19
df - Ø 元件固定14
Tins - 扭矩 (Nm)60
hef - 有效深度70
hnom - 最小锚固深度80
h1 - 钻孔最小深度85
d0 - Ø 钻头12
hmin - Min. substrate thickness140
L- 长度180
M12 x 200 Ø12
104
140
M
0
50
150
tfix - 最大夹具厚度104
SW-安装关键19
df - Ø 元件固定14
Tins - 扭矩 (Nm)60
hef - 有效深度70
hnom - 最小锚固深度80
h1 - 钻孔最小深度85
d0 - Ø 钻头12
hmin - Min. substrate thickness140
L- 长度200
M16 x 125 Ø16
8
170
G
0
25
100
tfix - 最大夹具厚度8
SW-安装关键24
df - Ø 元件固定18
Tins - 扭矩 (Nm)100
hef - 有效深度85
hnom - 最小锚固深度97
h1 - 钻孔最小深度105
d0 - Ø 钻头16
hmin - Min. substrate thickness170
L- 长度125
M16 x 145 Ø16
28
170
I
0
25
100
tfix - 最大夹具厚度28
SW-安装关键24
df - Ø 元件固定18
Tins - 扭矩 (Nm)100
hef - 有效深度85
hnom - 最小锚固深度97
h1 - 钻孔最小深度105
d0 - Ø 钻头16
hmin - Min. substrate thickness170
L- 长度145
M16 x 175 Ø16
58
170
K
0
25
50
tfix - 最大夹具厚度58
SW-安装关键24
df - Ø 元件固定18
Tins - 扭矩 (Nm)100
hef - 有效深度85
hnom - 最小锚固深度97
h1 - 钻孔最小深度105
d0 - Ø 钻头16
hmin - Min. substrate thickness170
L- 长度175
M16 x 220 Ø16
103
170
O
0
25
50
tfix - 最大夹具厚度103
SW-安装关键24
df - Ø 元件固定18
Tins - 扭矩 (Nm)100
hef - 有效深度85
hnom - 最小锚固深度97
h1 - 钻孔最小深度105
d0 - Ø 钻头16
hmin - Min. substrate thickness170
L- 长度220
M20 x 170 Ø20
32
200
K
0
20
40
tfix - 最大夹具厚度32
SW-安装关键30
df - Ø 元件固定22
Tins - 扭矩 (Nm)200
hef - 有效深度100
hnom - 最小锚固深度114
h1 - 钻孔最小深度125
d0 - Ø 钻头20
hmin - Min. substrate thickness200
L- 长度170
M20 x 200 Ø20
62
200
M
0
20
40
tfix - 最大夹具厚度62
SW-安装关键30
df - Ø 元件固定22
Tins - 扭矩 (Nm)200
hef - 有效深度100
hnom - 最小锚固深度114
h1 - 钻孔最小深度125
d0 - Ø 钻头20
hmin - Min. substrate thickness200
L- 长度200
[HIGH-LOAD ANCHOR] Male anchor for securing high-load elements in materials such as cracked and non-cracked concrete. It allows structural and non-structural elements to be secured with the utmost reliability.
[APPROVED ANCHOR] Anchor bolt approved to the highest quality standards. It holds European approval ETA 12/0397 (Option 1), which guarantees its performance in both cracked and non-cracked concrete; with CE marking; with seismic approval C1 (for models M8 to M20) & C2 (for models M12 to M20) and with fire resistance approval R30-R120.
[EASY INSTALLATION] Torque-controlled expansion anchor. It can be easily installed using a torque wrench. The design of its clip facilitates expansion. It features depth markings for correct installation.
[HIGHLY VERSATILE ANCHOR BOLT] It can be used in the installation of elements such as overhead lines, lifts, bridges, street furniture or high-strength fencing, amongst others.
[ATLANTIS C4-M STEEL SHAFT AND CLIP] The anchor is made from ATLANTIS C4-M steel. This is a corrosion-resistant material that guarantees the durability of the installation in locations such as industrial processing plants, polluted urban areas, industrial zones and coastal areas without salt spray.
